CH31
2.54mm Single Row Right Angle SMT Pin Headers
◎ Current rating : 3A 250V AC(r.m.s)
◎ Dielectric Withstanding Voltage : 1500V AC for one minute
◎ Contact Resistance : ＜20mΩ
◎ Insulation Resistance : ＞1000MΩ
◎ Operating Temperature : -40℃ ~ 105℃
◎ RoHS Compliant
| CIRCUITS | 2~40 CIRCUTS | ||
|---|---|---|---|
| Plating Code | 2= Gold Flash Plated over 50μ” Nickel | ||
